• Material: ABS plastics.
  • Dimensions: 137 × 46.6 × 22mm (L×W×H).
  • Weight: 110g (inclusive of battery).
  • Display Specification: 128 *48 matrix LCD.
  • Apparent Area: 35.81 x 14.37mm.
  • LCD shows signal strength, communication status, low battery indication, etc.
  • Display Content: English/numbers/icons.
  • User Input: 17 buttons, details as below
  • 1 key for OK
  • 1 key for cancel
  • 3 keys for vote
  • 10 keys for 1 / A ~ 10 / J
  • 2 keys for turning up/down
  • Battery & Replacement: 1.5V AA*2
  • Battery Information: operating time 150h, standby time 200h
  • RF Technology: Communication band 433MHz, patented and proprietary SunVote ARS communication protocol, bidirectional data validation, automatic channel tracking in fixed mode.
  • Channel number between 1 to 32.
  • RF power: < 10mW (10dBm).
  • Operating Distance: Within 80 meters.
